Using rcc to reshard a redis cluster using keyspace notification

Introduction

rcc comes with 2 important tools, one for analyzing the keys access accross nodes, built on top of redis keyspace notifications (which in turns runs on top of redis PubSub). The instrumentation is done over a period of time to sample the key access patterns. A 'weights' file is created as part of this tool. That file is saved in the current working directory by default. It is a very simple csv file that show how often a key is accessed.

$ head weights.csv
_pubsub::foo,50
_pubsub::bar,53
_pubsub::baz,7
_pubsub::buz,19
_pubsub::blah,940
_pubsub::blooh,20
_pubsub::xxx,552
_pubsub::yyy,571
_pubsub::zzz,92
_pubsub::foo,5035

The second tool is used to reshard a cluster, and migrate slots to node using the bin-packing algorithm. To feed this algorithm, weights are required.

Generating redis cluster traffic.

We use the cobra publish in batch mode command to send data to cobra, which internally send lots of XADD commands to our redis cluster.

The redis cluster is started with: rcc make-cluster ; rcc has a convenience sub-command to generate config file for cluster (by default 3 masters and 3 replicas), and finally initialize the cluster.

Keyspace access analysis before resharding

rcc keyspace --redis_url redis://localhost:11000 --timeout 10
...
== Nodes ==
# each ∎ represents a count of 105. total 15515
127.0.0.1:11000 [  6789] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
127.0.0.1:11002 [  4983] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
127.0.0.1:11001 [  3743] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎

Resharding

$ rcc reshard --redis_url redis://localhost:11000
file descriptors ulimit: 1024
resharding can be hungry, bump it with ulimit -n if needed
== f3fa13802f339abb98ccb377e8a1a4eb957be987 / 127.0.0.1:11000 ==
migrated 0 slots
Waiting for cluster view to be consistent...
.== 8c67b776ab52ad756777866dcb8425cc866c71a3 / 127.0.0.1:11001 ==
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrated 10 slots
Waiting for cluster view to be consistent...
............== d50246e7e3914639759add181c71a2e3c879ed2f / 127.0.0.1:11002 ==
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrating 1 keys
migrated 11 slots
Waiting for cluster view to be consistent...
.....total migrated slots: 11

It roughtly looks like we took slots away from the first node, and gave them to the other two redis instances.

Keyspace access analysis after resharding

rcc keyspace --redis_url redis://localhost:11000 --timeout 10
...
== Nodes ==
# each ∎ represents a count of 79. total 15114
127.0.0.1:11002 [  5087] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
127.0.0.1:11000 [  5040] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
127.0.0.1:11001 [  4987] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎

Larger Cobra cluster

Using application level sharding

Cobra uses consistent hashing to compute a shard/node id. The distribution of load is not very good on production data.

# each ∎ represents a count of 15417. total 5003266
 172.25.241.24:6379 [940378] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.24.239.218:6379 [879581] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.24.244.78:6379 [690303] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.24.86.253:6379 [627516] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.24.56.49:6379 [431098] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.28.138.193:6379 [343696] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.29.62.140:6379 [340555] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.26.145.223:6379 [277856] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.25.184.203:6379 [258128] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.31.104.188:6379 [214155] ∎∎∎∎∎∎∎∎∎∎∎∎∎
Mean Median Stddev Stddev/Mean
500326.6 387397.0 265549 0.530

The standard deviation is very high. Some nodes do way more work than others.

Using redis-cluster, before resharding

# each ∎ represents a count of 13921. total 5000873
  172.26.42.94:6379 [849140] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.27.86.24:6379 [796878] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.27.36.226:6379 [759250] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.26.25.36:6379 [718014] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.24.34.11:6379 [409835] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.24.244.119:6379 [391286] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.25.145.138:6379 [386700] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.26.32.220:6379 [348391] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.25.225.42:6379 [341379] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
Mean Median Stddev Stddev/Mean
555652 409835 217322 0.391

The standard deviation decreased from 265500 to 217322, the ratio between the standard deviation and the mean is smaller.

After the binpacking resharding

# each ∎ represents a count of 10615. total 5004030
 172.27.36.226:6379 [647515] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.26.25.36:6379 [581910] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.24.244.119:6379 [566576] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.27.86.24:6379 [562850] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.24.34.11:6379 [560954] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.25.225.42:6379 [551802] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
  172.26.42.94:6379 [536849] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
172.25.145.138:6379 [499993] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
 172.26.32.220:6379 [495581] ∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎∎
Mean Median Stddev Stddev/Mean
556003 560954 45278 0.081

Visually we can see that the distribution is very well balanced. The Stddev/Mean ratio decreased by a factor of 6.5 (0.530 / 0.81).
